Leak Testing Machine Manufacturer
Aplomb Machines India Private Limited is a trusted Leak Testing Machine Manufacturer that designs and develops high-performance testing systems for different industrial applications. We offer reliable, efficient, and customized solutions that help businesses improve product quality while reducing production costs. Whether it is automotive components, medical devices, plastic containers, valves, or industrial equipment, accurate leak testing helps manufacturers deliver defect-free products.
Leak Testing Machine Manufacturer, Supplier in India
A leak testing machine is a specialized quality control system used to detect leaks in components, containers, assemblies, or finished products. It verifies whether a product is completely sealed and capable of performing its intended function without allowing air, gas, or liquid to escape.
Modern leak testing systems use advanced technologies such as pressure decay, vacuum decay, differential pressure, mass flow, and helium leak detection depending on the application and required accuracy. These machines help manufacturers identify defective products before they reach customers, ensuring safety and reliability.
Features of Leak Testing Machine:
- Supports multiple testing methods (pressure decay, vacuum, helium, etc.).
- High-sensitivity sensors for precise leak detection.
- Fully automated testing cycles for consistency and speed.
- Non-destructive testing suitable for production lines.
- Real-time data logging and test result traceability.
- Leak size measurement for detailed analysis
| Specification | Details |
|---|---|
| Leak Volume Measurement | Pa, kPa, mL/s, mL/min, L/min |
| Leak Volume Display | 3 to 5 digits (floating point), sample rate: 10/second |
| Leak Limit (Standard) | ±999.9Pa or less |
| Number of Channels | 32 channels (option for 100 channels) |
| Timer Setting Range | 999.9 seconds (resolving power: 0.1 second) |
| Power Source | AC100 to 240V±10%, 50/60Hz, 80VA max |
| Test Pressure Source | Clean air, original pressure higher than test pressure |
| Pilot Pressure Source | 400 to 700kPa of clean air |
| CPU | ARM9 400MHz, DRAM 128MB |
| Display | 5.7 inch color LED, 640 x 480 pixels (VGA) |
| Pipe Connection Diameter | Rc(PT) 1/4 |
| Operating Temperature | 5 to 45°C |
| Storage Temperature | -20 to 60°C |
| Humidity Conditions | 80 %RH or less, no dew condensation |
| Weight | Approx. 13.5 to 17.5 kg (depends on model) |
| Serial Communications | RS232C-based (D-sub9-pin) 2 ports |
| USB Port | Copy CSV to USB for test data transfer |
| LAN Port | FTP server (in preparation) |
| Calibration/Maintenance Ports | M10 x 1.5 (O-ring seal) |
| E/P Regulator Repeatability | ±0.5% of F.S. or less |
| Standard Accessories | Power cord, control I/O connector, operation manual CD |
As industries continue to demand higher quality standards, investing in an advanced leak testing machine has become essential for manufacturers. Accurate leak testing helps eliminate defective products, improve production efficiency, and maintain customer satisfaction. Whether you manufacture automotive parts, industrial components, medical devices, or consumer products, reliable leak detection ensures consistent product quality. We deliver innovative, reliable, and customized testing solutions for modern manufacturing industries. We offer high-performance machines built with advanced technology, precision engineering, and user-friendly automation to help businesses achieve superior quality control.
